Place of Origin: | Malaysia |
Brand Name: | Allen Bradley |
Model Number: | 1769-IF4 |
Packaging Details: | Factory Seal |
---|---|
Delivery Time: | 0-3 days |
Payment Terms: | T/T, PayPal, Western Union |
Supply Ability: | 100 pcs/day |
Description: | CompactLogix 6 Pt RTD Module | Weight: | 0.29 KG |
---|---|---|---|
Memory: | 4 Points |
1769-IF4 1769IF4
DIGITAL INPUT MODULES
Input Module,CompactLogix,Analog,4 Point, 4 Single-Ended Inputs,14 Bit Resolution,Current and Voltage
Product Details
I/O Modules | |
---|---|
Digital Input Modules | Input Module,CompactLogix,Analog,4 Point, 4 Single-Ended Inputs,14 Bit Resolution,Current and Voltage |
The 1769 Compact I/O modules can be used as local I/O modules with these controllers:
• CompactLogix 5370 L2 controllers
• CompactLogix 5370 L3 controllers
• Compact GuardLogix 5370 controllers
• 1768 CompactLogix controllers
The modules mechanically lock together with a tongue-and-groove design and have an integrated communication bus that is connected from module to module by a moveable bus connector.
Each I/O module includes a built-in removable terminal block with fingersafe cover for connections to I/O sensors and actuators. The terminal block is behind a door at the front of the module. I/O wiring can be routed from beneath the module to the I/O terminals.
For detailed specifications, see 1769 Compact I/O Modules Specifications Technical Data, publication 1769-TD006.
1769 Analog RTD and Thermocouple Modules
1769-OF4 1769-OF4K(1) 4 outputs, single-ended ±10V 0…10V 0…5V 1…5V 0…20 mA 4…20 mA 15 bits plus sign unipolar and bipolar 120 mA @ 5.1V 170 mA @ 24V 8 1769-OF4CI 1769-OF4CIK(1) 4 outputs, differential, individually isolated 0…20 mA 4…20 mA 16 bits (unipolar) 165 mA @ 5V 110 mA @ 24V 8 1769-OF4VI 1769-OF4VIK(1) 4 outputs, differential, individually isolated ±10V 0…10V 0…5V 1…5V 15 bits plus sign (bipolar) 145 mA @ 5.1V 75 mA @ 24V 8 1769-OF8C 1769-OF8CK(1) 8 outputs, single-ended 0…20 mA 4…20 mA 16 bits (unipolar) 140 mA @ 5.1V 145 mA @ 24V 8 1769-OF8V 1769-OF8VK(1) 8 outputs, single-ended ±10V 0…10V 0…5V 1…5V 16 bits plus sign (bipolar) 145 mA @ 5.1V 125 mA @ 24V 8 (1) Module has conformal coating. Cat. No. Inputs/Outputs Sensors Supported Backplane Current Power Supply Distance Rating 1769-IR6 1769-IR6K(1) (1) Module has conformal coating. 6 RTD inputs 100, 200, 500, 1000 Ω Platinum 385 100, 200, 500, 1000 ΩPlatinum 3916 120 Ω Nickel 618 120 Ω Nickel 672 10 Ω Nickel-iron 518 0…150 Ω 0…500 Ω 0…1000 Ω 0…3000 Ω 100 mA @ 5.1V 45 mA @ 24V 8 1769-IT6 1769-IT6K(1) 6 thermocouple inputs Thermocouple types B, C, E, J, K, N, R, S, T ±50V ±100V 100 mA @ 5.1V 45 mA @ 24V 8(2) (2) To reduce the effects of electrical noise, install the 1769-IT6 module at least two slots away from the AC power supplies.
1769 Expansion Cables
If you divide 1769 modules into multiple banks, make sure:
• Each bank needs its own power supply.
• To use expansion cables to connect the banks.
• The last I/O bank requires an end cap.
Shipping Terms
Lead time: |
1-2 days |
---|---|
Courier: | DHL / UPS / FedEx |
Courier Shipping time: | 1-3 Days |
Packing: | NEW in Original packing / Used in neutral packing |
New: | Twelve Months (One year) |
---|---|
Used: | Three Months |
